Waste Plastic Pyrolysis Plant

The waste plastic pyrolysis plant produced by Beston Machinery has brought hope to dispose of plastic waste, one of the most annoying wastes on the planet. We have designed a set of technologies to help the waste plastic convert to fuels. Waste plastic turns into oil and carbon black under an oxygen-free environment through the process of pyrolysis. The primary end product of the processing, pyrolysis oil, also called as plastic oil can be used as fuel directly or be reprocessed and purified for better use.

waste plastic pyrolysis plant
Beston Waste Plastic Pyrolysis Plant for Sale

Note: The oil yield of plastic pyrolysis plants is high and different in the types of plastic.

Types of Plastic Coming from Oil yield
PE films, bottles, electrical insulating materials, handbags, bottles/calcium bottles, daily necessities, etc. 95%
Polypropylene (PP) films, plastic rope, tableware, pots, barrels, furniture, bags, caps, car bumpers, etc. 90%
Polystyrene(PS) electrical appliances, stationery, cups, food containers, appliance housings, electrical fittings, foam products, toys, etc. 90%
ABS plastic N/A 40%
Pure white plastic sheeting N/A 70%

oil yield of plastic pyrolysis plant

Exporting Cases of Beston Waste Plastic Pyrolysis Plant

Raw Material – Plastic Waste
Final Product - Plastic Oil
Final Product – Plastic Oil
Plastic Pyrolysis Oil
Plastic Pyrolysis Oil

Our waste plastic pyrolysis machine is well-designed and has good quality. It mainly consists of the auto screw conveyor, casing, reactor, manifold, condenser, heavy oil tank, oil storage tank and de-dusting system. Different from most of the waste pyrolysis plant manufacturers, we add refractory material between the casing and reactor. The material can protect the reactor against over-high temperature to prolong its lifespan, and at the same time, it can reduce energy consumption caused by heat loss.

Specification and Parameters

ModelBLJ-3BLJ-6BLJ-10BLJ-16BLL-16BLL-30
Capacity1-3t/d4-6t/d8-10t/d12-16t/d8t/d (only for rubber powder)30-35t/d
Working ProcessBatchBatchBatchBatchSemi-continuousFully continuous
Reactor Sizeφ1400*4900mmφ2200*6000mmφ2600*6600mmφ2800*7100mmφ2800*7100mmφ1800*18500mm
Reactor MaterialQ245RQ245RQ245RQ245RQ245R310S stainless steel
Drive System350 reducer+4kw drive motor400 reducer+5.5kw drive motor400 reducer+5.5kw drive motor500 reducer+7.5kw drive motor500 reducer+7.5kw drive motorZQH650-50 reducer+15kw frequency conversion motor
Land (L*W*H)18m*4.2m*6m30m*12m*8m30m*13m*8m33m*13m*8m33m*13m*8m70m*20m*10m
Power16.65kw37.85kw44.3kw55.6kw55.6kw256kw
Burner2*200,000 kcal2*300,000 kcal2*300,000 kcal2*400,000 kcal2*400,000 kcal2.5 million kcal per set
Total Weight of Shipped MaterialsAbout 18tAbout 24.5tAbout 28tAbout 34.5tAbout 34.5tAbout 150t
Number of Containers1*40HQ1*40FR+1*40HQ+1*20 GP1*40FR+2*40HQ1*40FR+2*40HQ1*40FR+2*40HQ25m*8m bulk cargo+8*40HQ
Noise (dB)≤60≤60≤60≤60≤60≤60
Heating MaterialsFuel oil (including tyre/plastic pyrolysis oil), natural gas, LPG, diesel, etc.
Condensing SystemVertical Condenserφ426*3000
Single piece condensing area
7.58m2
φ630*3600
Single piece condensing area
17.8m2
φ630*3600
Single piece condensing area
17.8m2
φ820*3600
Single piece condensing area
35.6m2
φ820*3600
Single piece condensing area
35.6m2
φ920*3200
2 sets of vertical condenser
3-in-1 Condenser3000*2200*2250
Condensing area
17.51m2
5800*2260*2500
Condensing area
35.85m2
5800*2260*2500
Condensing area
35.85m2
8000*2260*2500
Condensing area
49.5m2
8000*2260*2500
Condensing area
49.5m2

Advantages of Beston Waste Plastic Pyrolysis Plant Design

  • We use auto welding technique to greatly improve working efficiency and guarantee the welding quality simultaneously.
  • The hydro seal can stop the fire burning back while removing sulfur, impurities and keeping the oil gas clean.
  • Professional thermometer and pressure gauge are configured to inspect temperature and pressure at any time.
  • The feeding system and the discharging system are all sealed to make sure safety, working place sanitary and make sure there’s no heat loss during the pyrolysis process.
  • Tube-typed condenser is used to enlarge the condensing areas so as to improve the working efficiency of the plant.
  • We have high-leveled security design with 100% anti-burn technology and explosion-proof technology and outlet valve clogging-proof technique.
  • In the daily operation, the exhaust gas room is closed. When the pressure is too large, the exhaust gas room can be opened, so the combustible gas will be burned to lower the temperature and air pressure of the reactor.
  • We have various types of pyrolysis equipment for plastic for sale, such as batch-type (also called small scale pyrolysis plant), semi-continuous and fully continuous waste plastic pyrolysis plant. The clients can choose freely according to their actual needs.
Beston plastic pyrolysis plant
Installation Site of Beston Plastic Pyrolysis Plant in Romania

Operation Flow of Waste Plastic Pyrolysis Equipment

  1. The screw feeder feeds plastic wastes into the reactor automatically. But if you choose the batch type machine, the feeding will be operated manually. The oil gas will be generated as the interior temperature of the pyrolysis reactor get to related temperature after heating.
  2. The oil gas enters into the manifold, heavy particles of the oil gas will be liquefied into heavy oil and dropped into heavy oil tank; the light oil gas will be liquefied into fuel oil by the condenser and reserved in fuel oil tank.
  3. Combustible gas produced by the pyrolysis process will be desulfurated and cleansed in the hydro seal and then be recycled in the burning room as the heating source.
  4. The smoke generated when heating the reactor will be cooled down in the flue condenser at first. After that, it will go to the de-dust system and spray tower for de-dusting, washing, water spray, ceramic ring adsorption and activated carbon absorption. Finally, it will be discharged safely, meeting the EU environmental protection and emission standards.

working process of waste plastic pyrolysis machine

Our Superiority

  • Our plant has high quality, high efficiency and a high performance cost ratio.
  • Professional operating techniques make sure that we can deal with all the bugs during production.
  • Beston provides professional and perfect before-and-after sales services since we have rich experiences of exporting.
  • The clients can gain considerable profits from high-quality end products.
  • The clients have more options when selecting our products.

Except for this waste plastic pyrolysis plant, we have many other recycling plants for all kinds of solid wastes. Should you want to know more about our products, please go back to the homepage for more information or leave your message to us directly now.
